Description
- Frame: Alloy A1-6061 T6 Custom tubing, smooth welding, cross fun geometry, shark spine EVO, sport drive rear motor, disc brake post mount, fender & kickstand ready dropout, replaceable RD hanger, inner cable routing
- Head set: FSA No.10 Semi-cartrige, 1-1/8”
- Fork: Cross hybrid, alloy custom tubing, hi-ten steerer, ahead 1-1/8”, disc brake post mount, QR type
- Gears: 1x9
- Shifter: Shimano Altus SL-M2010-9R RapidFire Plus, 9-speed
- Front derailleur: Shimano Altus RD-M2000 Shadow
- Crankset: Wheel Top SXB5B130A-ED2WR, 42T
- Cassete: Shimano CS-HG200-9, 11-3 6T
- Bottom Bracket: NCTE SBBRF 120mm, BSA, shell 68mm
- Chain: KMC e9S
- Pedals: Marwi SP-160
- Handlebar: ONE1 Sport, MHB, AL-6045BT, 9° backsweep, 680mm, 31.8mm
- Stem: ONE1 MAS-D61808 Alloy, 31.8mm
- Grips: Velo VLG-1777D2
- Brakes: Shimano BL-MT200/BR-MT200, 160/160 rotor, hydraulic disk brake
- Saddle: WTB Volt Sport
- Seat Post: ONE1 Alloy, SP C207, 27.2MM
- Front Hub: ONE1 KTTD8F, 36H, M9x100mm, QR Type
- Rear Hub: Dapu M155, 36H, MOTOR, QR Type
- Rims: WTB SX19, 36H
- Tires: WTB Riddler Comp, 29x1.75”, Reflective Stripe
- Spokes: Sapim Galvanized Black
- Drive Unit: SPORT DRIVE M155 36V, 250W, 40Nm with Torque sensor
- Battery: SPORT DRIVE semi-integrated downtube battery 36V, 500 Wh
- Display: SPORT DRIVE Compact display
- Charger: SPORT DRIVE standard charger, 36V/2A, charging time up to 7.5 hours
- Charge cycles: 1000/80% of original capacity
- Front light: AXA Blueline 30
- Rear Light: Busch+Muller ILU SR
- Weight: 22.2kg
**Some minor assembly is required. See our video (below the image) or consult our assembly guide for assistance.
